| Model |
DF-4103 |
| Image Pick-up Device |
1/3" SHARP COLOR
CCD |
| Horizontal
Resolution |
420 TV
Lines |
| Number of
Pixels |
NTSC:510(H)x492(V);
PAL:500(H)x582(V) |
| Scanning
System |
NTSC:525
Lines,60 Field/sec,
PAL:625 Lines 50
Field/sec |
| Sync
System |
Internal
Synchronization |
| Gamma
Characterlstic |
0.45
|
| S/N
Ratio |
>=48dB(AGC
Off) |
| Electronic
Shutter Time |
On: NTSC
1/60~1/100,000Sec,PAL 1/50~1/100,000Sec;
Off:
NTSC 1/60 Sec, PAL 1/50 Sec |
| Usable
Illumination |
1 Lux(F:2.0),0
lux with built-in IR LED |
| IR projecct
distance |
15 meters(18
Unit Infrared LED) |
| IR
Status |
Under 10 Lux by
CDS |
| IR Power
On |
CDS Auto
Control |
| Lens |
Board Lens
3.6mm/F2.0(optional) |
| Video
Output |
1.0Vp-p 75
ohm |
| Gain
Control(AGC) |
Auto |
| Cable |
BNC
JACK |
| Water
resistance |
IP66 |
| Operation
Temperature |
-10 degree C to +50 degree C RH95%
Max |
| Storage
Temperature |
-20 degree C to +60 degree C RH95%
Max |
| Power
Supply |
DC12V+/-10% 600mA
|
| Dimension |
75(W)X45(D)X75(H)mm |
| Weight |
300g |
